NBrand:聽FORENSICS DETECTORS
Model:聽FD-90A-CO2-10%
User Manual:
Blog Article:聽

Features:

• 鈿涳笍 DETECT: Single-gas detector for carbon dioxide, 0 - 10% with 0.01% resolution. Comes FACTORY-CALIBRATED.
• 馃攱ACCURACY: Dual Beam NDIR sensor with Error: 鈮?5% F.S. and response time: < 30 sec. Zero and span calibration options.聽
• 馃巻 ALARMS: Adjustable audio, visual, and vibration alarms alert when preset levels are reached.
• 馃挭 STRONG: Shockproof, water-resistant, dust-proof, and explosion-proof.聽
• 馃暤锔?TRUSTWORTHY: ** 1-year limited warranty ** Arrives with calibration and QA certificates ** Product tested and verified in the USA **聽

Details:聽A perfect detector to confirm incubator CO2 levels. Constructed for professional industrial technicians that are looking to detect CO2 beyond basic ambient measurements.聽Excellent聽for isolated CO2 measurement in tanks, , storage rooms, fermentation processes, and industrial processes. For those seeking a higher range over 10%, we recommend our For those requiring ppm level for indoor air quality, we have our

Which CO2 Gas Monitor shall I purchase for my incubator?

It all depends on your incubator. For example:聽

1. If your incubator has a sample air port, then you need the聽. This analyzer has a built in pump and will draw the air from the incubator to the analyzer. This is the ultimate and best most accurate way to test.
2. If your incubator does NOT have a sample air port, but does have a glass window door, you can use the聽, and place the CO2 monitor in the incubator.聽 Versatile, but not as accurate as using聽the 聽as explained in step 1.
3. If your incubator does NOT have a sample air port, and does NOT have a glass door window then you will need to engineer access to the incubator and use the聽 so the analyzer can draw the air from the incubator to the analyzer for gas analysis.聽

Included: CO2 gas detector, belt clip, sling, English manual, USB charging cable, calibration cover, and USA NIST calibration certificate.

Calibration Options:聽聽Calibration Service by Forensics Detectors
Calibration Tutorial (DIY)

Calibration Kit (DIY sold separately):聽
Calibration Gas (CO2)
Calibration Gas Regulator (C10)
Tubing

Other Accessories聽(sold separately):聽聽
Bump Gas (CO2)
Pump and Probe
Gas Detector Hard Case
Gas Detector Pouch
Gas Detector Stand
Coupler for Incubators

Specifications

Carbon Dioxide (CO2) Detection: 0 - 10% with 0.01% resolution
Calibration Location: Los Angeles, California, USA
Calibration Standard: USA NIST Traceable Gas Source
Recommended Calibration Period: 12 months
Gas Sensor Type: NDIR Gas Sensor
Gas Sensor Life:聽> 5 years
Error: 鈮?卤 5% F.S
Response Time: < 30 sec
Indicators: LCD indicates the time, concentration, internal temperature, and battery level聽
Alarm: Indication of alarm, fault, and low voltage with LED, sound, and vibration
Store / Operating Temp:聽0掳F - 122掳F
Store / Operating Humidity:聽<95%RH
Voltage: DC 3.7V Li-battery 1500 mAh
Working Time: > 24 hours
Charging Time: 3 hours
Explosion Rating: ATEX certified Ex ib IIC T4 Gb
Weight: 5 oz / 140 g (including battery)
Dimensions: 4.3 x 2.3 x 1.7 inches
